TINOX Solar Collectors

TINOX Solar Collectors,solar flat collector,solar system collectors *OEM *ISO,SOLAR KEYMARK,CE,TUV EN12975 REPORT *5 YEARS WARRANTY 1. More sizes and requirements can be discussed. 2. Noted that we are manufacturer and the price we can insure the most reasonable,so the quality and after sale service. 3. Your order are pretty welcomed! Thanks. Best Sputtering Solar Collectors STANDARD SPECIFICATION: Absorber coating: Selective magnetic blue sputtering(TINOX) Optical Performance: Absorption: 95% / Thermal Emission: 5% Frame Casing: Anodized Aluminum alloy Cover glass: Low iron tempered patterned glass Insulation: 25mm soft fiberglass layer + 25mm high- density fiberglass board Back sheet: embossed aluminum plate Sealing profile: EPDM Connection: Ø22/25mm Ext. Dimension: 2000 x 1060 x 82/95mm (L x W x H) Gross /Aperture area: 2 sqm/1.85/sqm Operation pressure: 650Kpa / 6.5bar MODEL SELECTION: Model Number HSC-02QT-8 Absorber fin Copper TP2 Riser tube Copper TP2- Ø10mm Header Copper TP2- Ø22 / Ø25mm Number of risers 8 EFFICIENCY CURVE: Model: HSC-02QT-8 Base on aperture area, G = 800W/sqm
